| Place of Origin: | Fujian, China |
|---|---|
| Brand Name: | HI-CREATE |
| Certification: | CE |
| Minimum Order Quantity: | 1 set |
| Price: | $10,000.00 - $50,000.00 / Set |
| Packaging Details: | Spray antirust oil on the surface of machine and cover PE film,then packed by seaworthy wooden cases(including all spare parts) |
| Delivery Time: | 60 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 2 Set/Sets per Month |
| Applicable Industries: | Manufacturing Plant | After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service |
|---|---|---|---|
| Local Service Location: | India | Showroom Location: | India, Bangladesh |
| Condition: | New | Product Type: | Facial Tissue |
| Processing Type: | Pulp Molding Machine | Power(W): | 37KW |
| Dimension(L*W*H): | 4.1*2.9*2.1M | Weight: | 4.5T, 1.8-4.5T |
| Warranty: | 1 YEAR, One Year | After-sales Service Provided: | Free Spare Parts, Video Technical Support, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support, Engineers Available To Service Machinery Overseas |
| Production Capacity: | 60-100m/min | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Marketing Type: | New Product 2020 |
| Warranty Of Core Components: | 1 YEAR | Core Components: | PLC, Pressure Vessel, Engine, Gear, Motor, Bearing, Gearbox |
| Raw Paper Material: | 12-18g/m2*2layout | Raw Paper Roll Core Dia.: | 3'(76.2mm) |
| Finished Products Folded Size: | (70-105)*(140-210)mm | Operate Speed: | 1600-6400 Sheets/min |
| Programme Controller: | PLC | Machine Speed: | 60-100m/min |
| Electric Voltage: | 380V Or 220V | Port: | Xiamen, China |
| High Light: | Automatic Toilet Seat Cover Making Machine,100m/min Toilet Seat Cover Making Machine,PLC Tissue Manufacturing Machine |
||
The Automatic Toilet Seat Cover Making Machine
Technical parameters:
|
Model(HC-L) |
2L |
3L |
4L |
5L |
6L |
7L |
8L |
|
Max. raw paper roll width(mm) |
420 |
630 |
840 |
1050 |
1260 |
1470 |
1680 |
|
Raw paper material |
12-18g/m2 x 2layers |
||||||
|
Max. raw paper roll dia. |
Standard φ1100mm or ≤1200mm |
||||||
|
Raw paper roll core dia. |
3'(76.2mm) |
||||||
|
Finished products opened size(mm) |
(140, 150, 160-210) *(140-210) (mm) |
||||||
|
Finished products folded size |
(70-105) * (140-210) (mm) |
||||||
|
Operate speed(sheets/min) |
1600 |
2400 |
3200 |
4000 |
4800 |
5600 |
6400 |
|
Mechanical driving |
Driven by stepless frequency control system |
||||||
|
Programme controller |
PLC control, touch screen |
||||||
|
Counting system |
Alternate stack by stack |
||||||
|
Pneumatic system |
3HP Air Compressor, Mini Pressure 5kg/cm2 Pa |
||||||
|
Machine speed |
60-100m/min |
||||||
|
Vacuum system |
5.5kw |
7.5kw |
11kw |
13.5kw |
16kw |
22kw |
37kw |
|
Main power |
2.2kw |
3kw |
4kw |
5.5kw |
7.5kw |
11kw |
15kw |
|
Machine size(m) |
4.1*1.3*2.1 |
4.1*1.5*2.1 |
4.1*1.7*2.1 |
4.1*2*2.1 |
4.1*2.3*2.1 |
4.1*2.6*2.1 |
4.1*2.9*2.1 |
|
Weight(ton) |
1.8T |
2.2T |
2.6T |
3.0T |
3.5T |
4.0T |
4.5T |
|
Electric voltage |
380V or 220V |
||||||
Packing & Shipping:
Our Company & Factory:
HI-CREATE is manufacturer for disposable hygiene products machinery development, design and producing, mainly in production line for baby diaper , sanitary napkin, waistband diaper , training pant(pull up) diaper, adult diaper , and a series of household paper, disposable products processing equipment for toilet paper, tissue paper, and napkin paper.
Our Office:
Our Services:
Our Visitors:
Our Certificates:
Our Exhibition:
Customer Message:
Customer’s Photos:
FAQ:
1. Are you a manufacturer or trading company?
We are a manufacturer with our factories, more than 10-year experience in this industry.
2. Where is your factory?
Our factory locates in Xidong Industrial Zone, Huian Town, Quanzhou, Fujian, China.
3. How long is the turnaround time?
It takes about 30-60 working days to finish. And it depends on different products and customized requirements.
4. How long is your delivery time?
15-60 days after order being confirmed. Detailed delivery date should be decided according to production season and order quantity.
5. Can your machine do customization for our products?
We could do some customization size to fit your products size according to your requirement.
